Product Specifications

Strapping Specifications

Model
STB 81
STB 83
STB 85
STB 77
STB 55
Tension Force Range
400 – 1200 N (Standard)
150 – 750 N (Soft)
900 - 2500 N (Standard)
400 - 1360 N (Soft)
1300 - 4500 N (Standard)
400 - 1600 N (Soft)
3000 – 7000 N (Standard)
1000 – 5000 N (Soft)
0 - 2300 N
Weight (incl. Battery)
3.8 Kg (8.4 lbs)
4.0 Kg (8.8 lbs)
4.2 Kg (9.3 lbs)
6.7 Kg
3.8 Kg
Dimensions (L x W x H)
367 x 149 x 135 mm
(14.5” x 5.9” x 5.3”)
367 x 149 x 135 mm
(14.5” x 5.9” x 5.3”)
367 x 152 x 138 mm
(14.5” x 6.0” x 5.5”)
416 x 157 x 158 mm
380 x 130 x 200 mm
Operation Mode
Auto / Semi / Manual
Auto / Semi / Manual
Auto / Semi / Manual
Auto / Semi / Manual
Manual
Approx. Charging Time
48 – 65 min
48 – 65 min
48 – 65 min
70 to 80 min
72 to 95 min
Variable Tension Speed Range
3.00
0 – 220 mm/s
0 – 150 mm/s
0 – 100 mm/s
-
Cycles per charge
Low Tension: up to 1000
Medium Tension: up to 800
High Tension: up to 600
Low Tension: up to 800
Medium Tension: up to 600
High Tension: up to 400
Low Tension: up to 800
Medium Tension: up to 500
High Tension: up to 300
Up to 450
Up to 750
Model
STB 81
STB 83
STB 85
STB 77
STB 55
Strap Type
PP & PET
PP & PET
PP & PET
PET
PET & PP
Width
9 – 10, 12 – 13 mm
(3/8”, 1/2”)
12 – 13, 15 – 16 mm
(1/2”, 5/8”)
15 – 16,  18 – 19 mm
(5/8”, 3/4”)
25 – 32 mm
9 – 19 mm
Thickness
PET 0.4 – 0.8 mm (.015”–.031”)
PP 0.5 – 0.8 mm (.019”–.031”)
0.5 – 1.0 mm (.019”–.040”)
0.8 – 1.3 mm (.031”–.051”)
0.9 – 1.3 mm
0.5 – 1.0 mm
